ETL Certified Horizontal Laminar Flow Cabinet

Introduction:

Laminar flow cabinet is a box-type air purification equipment that can provide local dust-free clean, sterile working environment class 100 (ISO Class 5) local operating environment. The polluted air in the working area can be artificially controlled through a special filter channel to avoid harm to people and the environment. In the working state, it can keep the performance parameters such as wind speed, air cleanliness, noise, vibration and lighting in the working space to meet the requirements of laboratory use, and is widely used in biological laboratories, medical and health and other related industries, which has a good effect on improving the process conditions, protecting the health of the operator, and improving product quality and yield.

Quantity:

Model

Features:

1. ETL certification, satisfy North American market.

2. With memory function in case of power-failure.

3. Audio and visual alarm(Abnormal airflow velocity).

Technical Parameters:

Model	BBS-H800	BBS-H1100	BBS-H1300	BBS-H1500	BBS-H1800
External Size(WDH)	800810(1720~1980)mm	1100810(1720~1980)mm	1300810(1720~1980)mm	1500810(1720~1980)mm	1800810(1720~1980)mm
Internal Size(WDH)	700500600mm	1000500600mm	1200500600mm	1400500600mm	1700500600mm
Work Surface Height	750~1010mm
Max Opening	440mm
Display	LCD display
Airflow Velocity	80~99fpm
Material	Working area: 304 stainless steel Main body: Cold-rolled steel with anti-bacteria powder coating Front window: 5mm toughened glass, anti-UV
Pre-Filter	Polyester fiber
HEPA Filter	One, 99.995% efficiency at 0.3μm
Noise	≤68dB(A)
Illumination	≥300lx
Waterproof Sockets	One socket(Double type), America standard, Max. Power: 500W
Power Supply	103.5~126.5V, 60Hz, 10A
Consumption	750W	950W	950W	950W	1150W
LED Lamp	10W*1	14W*1	14W*1	18W*1	22W*1
Standard Accessories	Manually height adjustable base stand, LED lamp, Wind speed sensor, Waterproof socket, Stainless steel. V. Bar with 10 hooks
Optional Accessories	UV lamp
Package Size(WDH)	94010901250mm	124010901250mm	144010901250mm	164010901250mm	194010901250mm
Gross Weight	150kg	190kg	225kg	265kg	300kg
