5-part Auto Hematology Analyzer BK-6310

Introduction:

The 5-part hematology analyzer is an in vitro diagnostic device developed based on laser flow cytometry analysis, nucleic acid fluorescence staining and other technologies, which can quantitatively and qualitatively analyze components such as red blood cells, white blood cells and platelets in the blood.

Quantity:

Model

Features:

1. Throughput 60T/H.

2. 14-inch touch screen.

3. Tri-angle laser scatter + flow cytometry method + impedance method for RBC and PLT counting.

4. 3D holographic scattergram displays the accurate 5-part differentiation of WBC.

5. Large storage capacity: 300,000 results(including histogram, scattergram, patient information).

Technical Parameters:

Model	BK-6310
Throughput	60 Tests/hour
Assay Items	5 parts, 29 parameters, 3 histograms, 3D scattergram
Principle	Tri-angle laser scatter, Flow cytometry method, 3D scattergram analysis, Impedance method for RBC and PLT counting, Cyanide-free method for HGB test
Test Mode	CBC mode, CBC+DIFF mode Venous whole blood, Capillary whole blood and Prediluted
Sample Volume	CBC+DIFF mode: ≤20μl CBC mode: ≤10μl
Parameters	WBC, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PCT, PDW, P-LCR, P-LCC, NEU%, LYM%, MON%, EOS%, BAS%, NEU#, LYM#, MON#, EOS#, BAS# 4 research parameters: ALY%, ALY#, LIC%, LIC#
Performance	Item	Linearity Range	Carry Over	CV
	WBC	0~300*10⁹/L	≤0.5%	≤2.0%
	RBC	0~8.6*10¹²/L	≤0.5%	≤1.5%
	HGB	0~260g/L	≤0.5%	≤1.5%
	PLT	0~3000*10⁹/L	≤1.0%	≤4.0%
Storage	300,000 results including histogram, scattergram and patient information
Interface	4 USB ports, 1 LAN port Bi-direction LIS, support HL7 protocol, Internal RFID reader
Power Supply	AC100-240V,50/60Hz, 300VA
Package Size(WDH)	575490690mm
Gross Weight	46kg
Reagent Package Size	330330330m, 400290240mm, 400290240mm
Reagent Gross Weight	22kg, 2kg, 2kg
